House with the garage

IMPROVE THE LOOK, SECURITY & EFFICIENCY OF YOUR PROPERTY AS WELL AS CONVIENENCE WITH OUR ELECTRIC ROLLER SHUTTER GARAGE DOORS

From our showroom & factory in Washington to homes across Tyne & Wear, County Durham, Teesside and Northumberland. Choose the right system for your usage needs and budget, without the pushy sales tactics. You can trust in Tyne and Wear Garage Doors.

We manufacture doors to THE TRADE and DIRECT TO THE PUBLIC with a typical turnaround time of 48hrs from point of order.


Contact us now for a free, no obligation site survey & quote!

ENJOY A 5-YEAR GUARANTEE ON ALL MOTOR INSTALLATIONS!

Make the most of your space, secure your premises, improve thermal efficiency and enjoy the convenience that a robust roller shutter brings to properties across Tyne and Wear. We’re proud to bring you a range of fantastic garage doors, each selected for their durability and quality, for a system that lasts.

Our domestic garage doors are constructed from components produced by one of Europe’s leading manufacturers. The twin-walled aluminium sections provide high levels of sound and thermal insulation which is further enhanced by the dual seals within the supporting side guide channel uprights. The use of 55mm or 77mm (dependent on model) insulated sections enable the doors to roll within a tighter overall diameter, considerably reducing the size of the head plate and enabling the doors to be installed in locations where others cannot be made to fit. Each shutter is supplied in white as standard, with a range of colours to choose from, including anthracite, beige and burgundy red, with supporting side guide channels and casings.

Garage doors are electronically operated and can be supplied with an internal or external manual override facility for use in the event of a power failure. Standard operation of the door is via a single, secure, ‘rolling code’ remote control which operates on the 433MHz band. Maximum safety is achieved by using ‘deadman’ locking operation.

HELPING YOU MAKE A CONFIDENT DECISION
  • 5-year guarantee on all motor installations as standard

  • Inclusive of manufacturer’s warranty

  • Supplied and installed by Tyne and Wear Garage Doors

  • Best price first time

  • 10-year colour fast

  • 12-month guarantee on all fittings

  • 5-year motor guarantee included

  • No-obligation quotes

  • Manual to electrical roller shutter conversions available

  • Ongoing maintenance and repairs available

We have a range of fittings available within the following shutter doors:

The CIS55

This is our compact insulated shutter, electrically operated and designed specifically for openings with minimal headroom above the lintol. These doors are highly competitive in price and an ideal replacement for a single traditional manually operated up-and-over door.
The SIS77
This is our superior insulated shutter which offers a significantly stronger option for wider garage door openings.

All of our shutter doors benefit from the following specifications:

Head plates

Featuring a polyester powder coated profiled cast alloy, with nylon guide blocks to maintain centre alignment of the door curtain at all times. The CIS55 profiles run at 205mm with the SIS77 at 300mm.

Barrel assembly

Both shutters have octagonal steel incorporating a nylon support and bearing at the non-driven end with the SIS77 measuring 70mm and the CIS55 60mm.

Motor

An integral tube motor drive with inbuilt manual override. Which benefits from our 5yr motor warranty.

Side guides

White polyester, powder coated, aluminium side guide channels, with dual seals to provide both thermal and sound insulation.

Curtain

Polyester powder coated, fully insulated, aluminium interlocking
laths, finished with a self-lubricating nylon end clip on every alternate section to ensure that the curtain is held square at all times.

Bottom rail

The door is finished at the base with a rigid, extruded, weighted, aluminium rail and superior rubber seal.

Control

Standard operation is via open/stop/close. Push buttons, mounted on the radio receiver or via one of two handheld transmitters supplied.

Safety

Press and release control button to fully open the door. Press and hold button depressed to close.

CE marking

All garage doors and related equipment is fully CE approved.

Locking

The door curtain is supplied with locking straps which hold the shutter in the closed position.

Casing

The whole barrel assembly is covered in a white polyester, powder coated aluminium front fascia with an interlocking back box.

Manual override

The manual override attachment, for use in the event of power failure, is situated to the underside of the casing and is only accessible from the inside. Operation of the manual override is with the supplied crank handle.

Garage Door Fixing Arrangements

Tyne and Wear garage doors offer free surveys with no obligation to buy, our survey will identify which installation arrangement best suits your specific requirements. All options are discussed in full to ensure you are confident that we understand your requirements.

1. If you are looking for a Maximum drive through opening we would always recommend our “ internal face fixed” arrangement.

fixing 1

2.  If you have a painted front door within a white surrounding frame we would suggest our “partial reveal fix”.

fixing 3

3. With the guide sitting partially behind the brickwork of between the brickwork “between wall fix”.

fixing 2
gold stars

WHAT OUR CUSTOMERS SAY

“Just had garage door fitted. Looks great. Very pleasant lads. Would recommend.”

Logo white

Find the most suitable product for your home or business. Call Tyne and Wear Garage Doors to get the right product at the right price!
